Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of portable water depth level meter in China. Welcome to buy high quality portable water depth level meter in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.
Technical Specifications
| Parameter | Specifications | Notes |
|---|---|---|
| Model | XBHV-11 (Steel Stand Type) | Manual portable reel |
| Measuring Range (Depth) |
30 m / 50 m / 100 m / 150 m / 200m /250m /300m |
Optional reel capacities |
| Minimum Resolution | 1.0 mm | Direct reading on tape |
| Repeatability Error | ≤ ±2.0 mm | Meets geotechnical survey standards |
| Probe Material | SUS304 Stainless Steel | Insulated internal electrode |
| Signal Alert Modes | Audible Buzzer + Analog Voltmeter Needle | Selectable via panel switch |
| Frame / Stand Type | Coated Tubular Carbon Steel | Heavy-duty steel feet with carry handle |
| Reel Material | High-impact ABS engineering plastic | Center hub houses battery & circuit |
| Operating Voltage | DC 9 V | Standard 6F22 / 9V alkaline battery |
| Total Net Weight | • 30m: ~3.5 kg • 50m: ~4.5 kg • 100m: ~6.5 kg • 150m: ~10.0 kg |
Varies by cable length |
| Operating Temperature | -10 °C to +40 °C | Storage humidity ≤ 80% RH |
Applications
- Groundwater Monitoring Wells: Verification of static and dynamic water levels during pumping tests.
- Geotechnical & Dam Safety: Inspection of phreatic infiltration lines in earth-rock dams, embankments, and tailings ponds.
- Drilling & Well Completion: Well drilling acceptance, water well drawdown tests, and casing depth checks.
- Construction Dewatering: Site groundwater table monitoring for deep excavation, tunnels, and mining shafts.
