Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of rs485 modbus tds sensor in China. Welcome to buy high quality rs485 modbus tds sensor in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.
Technical parameters
| Item | Specification |
|---|---|
| Principle | Two-pole graphite electrode |
| Measuring range | Conductivity 0–9999 µS/cm; conductivity 10.00–70.00 mS/cm; TDS 0–9999 ppm; salinity 0–40.00 ppt |
| Resolution | 1 µS/cm; 0.01 mS/cm; 1 ppm; 0.01 ppt |
| Accuracy | ±2.5% |
| Calibration period | > 3 months |
| Housing material | PPS |
| Cable length | 5 m standard; other lengths optional |
Advantages
- One electrode, five readings. Conductivity, TDS, salinity, resistivity and temperature come from the same body on the same cable. On a multi-parameter installation that removes probes, ports and wiring.
- Isolated supply and interference resistance. The supply is isolated and the input is designed to hold its data steady around pumps, aerators and VFDs - exactly where aquaculture and treatment-plant readings usually fall apart.
- Calibration from the control room. Standard solutions at 84 µS/cm, 1413 µS/cm, 12.88 mS/cm and 25 ppt, plus custom values, triggered by a Modbus command - no opening the housing, no screwdriver.
- Compensation you can actually match to the site. Reference temperature, coefficient, manual temperature and sensor factor are all writable, so the electrode can be brought into agreement with a laboratory or a reference meter.
- Faults that announce themselves. Overrange, calibration failure and missing-temperature-sensor codes are readable at address 0x09.
Applications
- Aquaculture
- Environmental protection and water treatment
- Industrial processes
- Water quality testing
- Information and data collection
- IoT water-quality testing
- Continuous monitoring in fresh water and sea water
