Name: China Online Industrial Turbidity Meter Manufacturers Suppliers Factory - Customized Service - Yheng
Brand: Yheng
SKU: 299139129

Online Industrial Turbidity Meter

The sensor emits a laser beam into the liquid under measurement. Suspended particles within the liquid generate scattered light. The receiver detects the intensity of this scattered light and converts it into a turbidity value by referencing the calibration table.

● High Precision & Automatic Compensation
● Durable & IP68 Waterproof Design
● RS485 + 4-20mA interface

Advantages
This online turbidity meter uses spectral absorption method with automatic temperature compensation for accurate measurement. It features SS316 electrode, IP68 waterproof, self-cleaning brush, easy English display, and dual outputs.

Send Inquiry

Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of online industrial turbidity meter in China. Welcome to buy high quality online industrial turbidity meter in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.

Specification	Value
Power Supply	DC 9-28V
Peak Power	5W
Light Source	860nm laser
Protection Class	IP68
Range	0 ~ 1000NTU
Resolutions	0.01NTU
Lower Measurement Limit	0.05NTU
Zero Drift	≤ 1.5%
Stability	≤ 1.5%
Accuracy	5% or±0.5 NTU (whichever is greater); (based on Formazin primary standard at 25℃)
Repeatability	≤ 1%
Response Time (T90)	≤ 120 seconds
Operating Temperature	-5 ~ 45 ℃
Calibration Method	Factory calibrated, use default calibration curve; single point calibration, Formazin two point calibration, 2 to 6 point custom calibration
Withstanding Pressure	0.6MPa
Inlet Flow	100 ~ 1000mL/min (500mL/min recommended)
Dimension	182mm*Φ32
Housing Material	ABS and POM plastic
Connector	RS485 + 4-20mA interface

Features

● Compact size, convenient for system integration;

● Simple structure, easy to clean and maintain;

● Inclined light window, not easy to adhere to air bubbles;

● Sealed structure, resistant to deep water or high pressure;

● IP68 protection, portable installation.

Applications

Turbidity Meter is mainly used in the safe guarding of water quality in many fields of production, applications range from drinking water, the pharmaceutical industry, chemical industry, fuel industry and motor development to the monitoring of the food and beverage industry.
