Rebound Hammer Calibration Anvil

TEM-80/TEM-60 Calibration Steel Anvil is a professional standard calibration tool specially designed for concrete rebound hammers.

● High-hardness Durable Material
● Precise Calibration Performance
● Easy Maintenance

Advantages
It provides accurate and stable rebound value calibration benchmarks to ensure the testing precision of rebound hammers in engineering applications. Compliant with international industry standards, this anvil is an essential auxiliary instrument for non-destructive concrete strength testing.

Send Inquiry

Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of rebound hammer calibration anvil in China. Welcome to buy high quality rebound hammer calibration anvil in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.

Index	TEM-80 Calibration Steel Anvil	TEM-60 Calibration Steel Anvil
Calibration Rebound Value	80±2	60±2
Applicable Hammer	N-type concrete rebound hammer (2.207J)	N-type concrete rebound hammer (2.207J)
Anvil Core Hardness	HRC58-62	HRC58-62
Dimension	Φ50×200mm	Φ50×166mm
Total Weight	1.6KGS	2.4KGS
Material	Premium steel + high-grade tool steel	Premium steel + high-grade tool steel
Compliance Standard	EN12504-2; ASTM D5873; ASTM C805	EN12504-2; ASTM D5873; ASTM C805
Accessory	Buffer rubber pads (fixed)	Buffer rubber pads (fixed)

Features

● High-Quality Material & Hardness: Crafted from premium steel and high-grade tool steel, the anvil core surface reaches Rockwell hardness of HRC58-62, ensuring wear resistance and long-term structural stability.

● Precise Calibration Benchmark: Delivers a standard rebound value of 80±2 (TEM-80) and 60±2 (TEM-60) for N-type concrete rebound hammers (2.207J), providing accurate calibration references for testing equipment.

● International Standard Compliance: Manufactured in line with EN12504-2, ASTM D5873 and ASTM C805, meeting global industry calibration and testing requirements for universal applicability.

● Practical Structural Design: Equipped with fixed buffer rubber pads (non-removable during use) for stable placement; the anvil core and body can be polished and leveled after 500-800 bounces to maintain calibration accuracy.

● Easy Maintenance & Storage: Requires simple maintenance-just keep it in a dry, dust-proof environment to prevent corrosion; the test surface is designed to avoid impact damage and preserve standard working status.

Applications

As a professional calibration accessory for rebound hammers, TEM-80/TEM-60 Calibration Steel Anvil is widely used in all fields that require concrete non-destructive testing and equipment calibration:
