TUF-2000F2 Integrated Type Ultrasonic Flow Meter

High-performance inline measuring device engineered in strict accordance with the JJG1030-2007 standard, adopting the transit-time ultrasonic measurement principle. It has a full IP68 waterproof rating with all components hermetically sealed, enabling underwater operation within 2m and stable performance in severe working environments

● Accuracy: ±0.5% for both π-Type and Standard Type
● Power Supply: AC 85V~265V/ DC 18V~36V
● Output: 4-20mA/RS485/Pulse/Hart

Advantages
The meter features strong anti-interference, reliable operation, multiple expandable interfaces, and no moving parts, ensuring long-term high-precision measurement and adaptability to diverse water quality including media with gravel and weeds.

Send Inquiry

Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of tuf-2000f2 integrated type ultrasonic flow meter in China. Welcome to buy high quality tuf-2000f2 integrated type ultrasonic flow meter in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.

Parameters	Specifications
Measuring Range	π-Type: DN15~DN32mm; Standard Type: DN40~DN1000mm
Accuracy	±0.5% for both π-Type and Standard Type
Temperature Range	-30℃~160℃ (measured fluid); -20℃~60℃ (converter)
Pressure Range	π-Type: 0~4.0Mpa; Standard Type: 0~2.5Mpa (optional)
Flange Standard	GB/T 9119-2000 (DN15~300); JB/T 81-94 (DN350~1000)
Fluid Velocity	0~7m/s
Turbidity Tolerance	≤10000ppm (little bubble allowed)
Interfaces	RS485 (MODBUS), 4-20mA analog I/O, OCT pulse, Relay signal
Power Supply	DC8~36V; AC85~264V (optional)
Power Consumption	1.5W

Features

● Complies with JJG1030-2007 standard, adopts transit-time ultrasonic measurement principle for stable detection.

● Full IP68 waterproof rating, all components hermetically sealed, operable underwater within 2m for severe environments.

● High anti-interference performance and reliable operation, with multiple expandable interfaces for easy system integration.

● No rotating or moving parts, realizes long-term high-precision measurement and low maintenance cost.

● Adaptable to various water quality (including media with gravel/weeds) and common pipe materials, strong universality.

● Dual precision grade of ±0.5% for flanged types, supports wide fluid temperature/pressure range for diverse working conditions.

● Low power consumption (1.5W) with dual power supply options (DC8~36V/AC85~264V), flexible for on-site use.

Applications

Electromagnetic flowmeters are widely used for accurate and reliable measurement of conductive liquids, including water, wastewater, corrosive fluids, slurries, and various process media. They offer stable performance, low maintenance, and wide compatibility with industrial processes.
