TUF-2000P Portable Ultrasonic Flow Meter

Enabling non-contact, non-invasive liquid flow measurement for closed pipes, ideal for flow surveys. It integrates an SD card and thermal printer for real-time/regular printing of preset measurement data, and can measure temperature and heat with a clamp-on temperature transducer. It supports long-term data storage and analysis via matching software, with multi-language display for easy operation across different regions.

● Pipe Diameter Range: DN15 ~ DN6000mm
● Measuring Principle: Transit time ultrasonic
● Medium Temperature: -30℃ ~ 160℃

Advantages
Non-invasive measurement without water cutoff or pressure loss, ensuring uninterrupted pipe operation

Send Inquiry

Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of tuf-2000p portable ultrasonic flow meter in China. Welcome to buy high quality tuf-2000p portable ultrasonic flow meter in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.

Item	Specifications
Measuring Principle	Transit time ultrasonic
Accuracy	±1%
Display	2×20 character backlit LCD
Pipe Diameter Range	DN15 ~ DN6000mm
Medium Temperature	-30℃ ~ 160℃
Flow Rate	0 ~ ±10m/s
Power Supply	8×1.2V Ni-MH batteries; 90V-260V AC adapter
Power Consumption	1.5W
Transducer Protection	IP67
Data Storage	2G external SD card
Pipe Material Compatibility	Steel, stainless steel, cast iron, copper, cement pipe, PVC, aluminum, glass steel (liner allowed)

Features

● Non-invasive measurement without water cutoff or pressure loss, ensuring uninterrupted pipe operation

● Dual transducer options (clamp-on/mounting bracket) with high-temperature variants for diverse scenarios

● Built-in Ni-MH batteries for over 20 hours of standalone use, plus AC adapter support for continuous operation

● Rich output/input signals and RS485 communication interface, compatible with MODBUS for software upgrade

● High-strength dustproof, waterproof and impact-resistant carrying case for easy portability

● Multi-language LCD display (Chinese, English, Italian) with backlight for clear reading

Applications

The TUF-2000P portable ultrasonic flow meter is a non-invasive (clamp-on) measuring instrument widely used in industrial, water, and energy management applications for flow monitoring and data recording of various liquids within closed pipelines. Its portability and non-stop installation (clamp-on) features make it particularly suitable for on-site flow calibration.
