Name: China Liquid Oval Gear Flow Meter Manufacturers, Suppliers and Factory - Customized Service - Yheng
Brand: Yheng
SKU: 299147635

Liquid Oval Gear Flow Meter

High-precision volumetric flowmeter for viscous/high-temp liquids, non-contact sensing, ideal for multi-industry liquid measurement.

● High precision for high-viscosity & high-temperature liquids
● Non-contact magnetic sensing, no media contact
● Low pressure loss, minimal operational energy consumption

Advantage
Volumetric design with high accuracy, wide media compatibility and flexible output for industrial viscous liquid measurement.

Send Inquiry

Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of liquid oval gear flow meter in China. Welcome to buy high quality liquid oval gear flow meter in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.

Code Type	Mark	Meaning
Special Type	T	High temperature type
	U	Insulation clamp type
	N	High viscosity type
	L	Low viscosity type
Material	B	304 stainless steel
	C	316L stainless steel
	L*	Aluminum alloy/Other customized materials
Nominal Pressure	.1	1.0Mpa
	.2	1.6Mpa
	.6	6.3Mpa (standard for all models)
Signal Output	GF	Pulse signal only
	BELZ	LCD display (lithium battery)
	BELZ-MF	LCD + 4-20mA signal
	BELZ-RS	LCD + RS485 signal
Connection	-F	Flange
	-L	Thread (default)
	-K	Chuck

Features

● Volumetric flow design, high accuracy and repeatability for liquid measurement

● Adapt to wide viscosity range, for high-viscosity and high-temperature liquids

● Low pressure loss, realizes minimal energy consumption during operation

● Multiple alloy body options, resistant to acid, alkali, salt and organic solutions

● Non-contact magnetic sensing, no contact with measured media

● High-resolution pulse output for ultra-fine measurement resolution

● Local digital LCD display for instantaneous and cumulative flow

● Supports pulse/4-20mA/frequency output for remote transmission

● Compact size, low straight pipe requirements, easy installation and calibration

Applications

Specialized in high-precision volumetric flow measurement of high-viscosity and high-temperature liquids, with wide media compatibility. Suitable for centralized control system integration, ideal for multi-industry liquid flow monitoring with stable and reliable performance.
