Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of digital submersible level transmitter in China. Welcome to buy high quality digital submersible level transmitter in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.
Technical Specifications
| Parameter | Specification |
|---|---|
| Compatible Media | Water (H2OH2O) and fluids compatible with wetted materials (PTFE optional for corrosive media) |
| Measuring Range | 0–1 to 50 mH2OmH2O |
| Accuracy Class | • ±0.5%FS±0.5%FS (Standard, 1m≤Span<10m1m≤Span<10m) • ±0.25%FS±0.25%FS (Standard, Span≥10mSpan≥10m) • ±0.1%FS±0.1%FS (Customized, Span≥10mSpan≥10m) |
| Output Signals | • 4–20mA (2-wire) • RS485 (Standard Modbus-RTU protocol) • HART Protocol (Optional for display version) • 0–10VDC, 0–5VDC, 1–5VDC, 0.5–2.5VDC (Customized) |
| Supply Voltage | • 8–30VDC (Standard compact model) • 12–30VDC (Display model / 0–10VDC output) • 24VDC (Ex ia intrinsically safe models) • 3–5VDC (Low-power customized model: 0.5–2.5VDC / RS485) |
| Media Temperature | 40 to 60∘C40 to 60∘C |
| Ambient Temperature | −40 to 85∘C−40 to 85∘C |
| Compensated Temperature Range | −10 to 60∘C−10 to 60∘C |
| Temperature Drift | ≤±0.01%FS/∘C≤±0.01%FS/∘C (Within compensated temperature range) |
| Long-Term Stability | ±0.1%FS/year±0.1%FS/year |
| Proof Pressure (Overload) | 200%FS200%FS |
| Vibration Tolerance | 10g (20 to 2000Hz) |
| Dynamic Response Frequency | • Analog Output: ≤500Hz≤500Hz • Digital Output: ≤5Hz≤5Hz |
| Explosion-Proof Rating | • Intrinsically safe: Ex ia IIC T6 Ga (4–20mA output) • Dust intrinsically safe: Ex iaD 20 T80℃ / Ex ia II C T6 Ga |
| Enclosure Protection | • Submersible Probe: IP68 • Junction Box: IP65 (Standard & Ex ia) / IP66 (Dust Ex ia) |
| Power Consumption | • Current output: ≤0.02 Us (W)≤0.02Us(W) • Digital output (RS485): ≤0.015 Us (W)≤0.015Us(W) • Voltage output: ≤0.008 Us (W)≤0.008Us(W) • Low-power voltage: ≤0.001 Us (W)≤0.001Us(W) (Us=Supply VoltageUs=Supply Voltage) |
| Net Weight | Probe + Terminal Enclosure ≈1070g≈1070g; Vented Cable ≈60g/m≈60g/ma |
Applications
- Deep Well & Groundwater Monitoring: Submersible installation for rural irrigation, geological survey, and borehole monitoring.
- Municipal Water & Pumping Stations: Raw water intakes, balancing tanks, clear water reservoirs, and booster stations.
- Wastewater & Drainage Systems: Sewage sumps, storm lift stations, aeration basins, and effluent weirs (utilizing 4.5mm anti-clogging design).
- River, Reservoir & Open Channel Hydrology: Level gauging in flumes, rivers, irrigation canals, and flood warning stations.
- Industrial Liquid Storage Tanks: Cooling towers, atmospheric equalization tanks, and neutral chemical holding basins.
