Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of fixed type pressure transmitter in China. Welcome to buy high quality fixed type pressure transmitter in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.
|
Pressure Types |
Gauge pressure, Absolute pressure |
|
Supply Voltage |
8-30VDC standard (3-5VDC customizable) |
|
Temperature Compensation |
-10°C to 70°C (standard), -40°C to 80°C (for 0.1% FS) |
|
Temperature Drift |
±0.01% FS/°C within compensated range |
|
Electrical Protection |
Current limiting, voltage limiting, reverse polarity protection (current output) |
|
Load Capacity |
Current type ≤{(Us-7.5)÷0.02}Ω, Voltage type ≥100kΩ |
Features
● High Accuracy: 0.1% FS accuracy for precise measurement
● Wide Pressure Range: 0 to 60MPa available (0-2.5~60MPa)
● Robust Construction: 316L stainless steel diaphragm with 304 stainless steel housing
● IP67 Protection: Dust-tight and protected against temporary immersion
● Multiple Output Options: Standard 4-20mA, with customizable voltage outputs
● Broad Temperature Range: Operating temperature -40°C to 85°C
● Excellent Stability: ±0.1% FS per year long-term stability
● Fast Response: ≤500Hz response frequency
● Overload Protection: 200% full scale overload capacity
● Vibration Resistant: 10g (20-2000Hz)
Applications
Industrial pressure transmitters are mainly used in industrial settings to continuously measure the pressure, level, and flow rate of liquids, gases, and steam, and output standard signals to the control system.
