Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of rs485 modbus cod sensor in China. Welcome to buy high quality rs485 modbus cod sensor in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.
Technical Specifications
| Parameter / Feature | Technical Specification |
|---|---|
| Model | lms-0-1500 |
| Measurement Method | UV254 absorption + 850 nm NIR reference |
| Measurement Range | COD: 0.1 ~ 1500 mg/L TOC: 0.1 ~ 750 mg/L BOD: 0.1 ~ 900 mg/L Turbidity: 0.1 ~ 4000 NTU Temperature: 0 ~ 50 ℃ |
| Accuracy | < 5% (KHP equivalent) Temperature: ±±0.5 ℃ |
| Power Supply | 9 ~ 36 VDC |
| Output / Protocol | RS-485 Modbus-RTU (9600-8-N-1) |
| Dimensions | Diameter: 32 mm, Length: 189 mm |
| Weight | Approx. 1.1 kg (including 10 m cable) |
| Wetted Material | Main Body: SUS316L stainless steel |
| Ingress Protection | IP68 / NEMA 6P |
| Pressure Range | ≤≤ 0.1 MPa |
| Cable Length | Standard 10 m shielded cable |
| Self-Cleaning System | Integrated motorized wiper |
| Operating Temperature | 0 ~ 50 ℃ |
| Storage Temperature | 0 ~ 45 ℃ |
| Calibration | Standard calibration (KHP solution) |
| Warranty | 12 months |
Advantages
- Reagent-Free Physical Optical Measurement
- Dual-Wavelength Beam with Auto Turbidity Compensation
- 5-in-1 Simultaneous Multi-Parameter Output
- Motorized Automatic Wiper Mechanism
- Rugged SUS316L & Submersible IP68 Housing
- Standard Industrial RS-485 Modbus-RTU
Applications
- Municipal Wastewater Treatment Plants (WWTP)
- Industrial Effluent Monitoring
- Surface Water & Environmental Protection
- Drinking Water & Source Water Safety
- Process Water & Water Recycling (Reclaimed Water)
