Dalian Yheng Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of portable pile integrity tester in China. Welcome to buy high quality portable pile integrity tester in stock here from our factory. If you have any enquiry about customized service, please feel free to email us.
|
System noise voltage |
≤2mV |
|
Sampling time interval |
2.0μs ~ 512.0μs |
|
Amplifier gain |
≤64dB (floating point) |
|
A/D resolution |
16bit |
|
Frequency response |
Acceleration 2～8000Hz; Speed 10～1000Hz (frequency error≤10％) |
|
Amplitude nonlinearity |
≤10％ |
|
Time indication error |
≤1％ |
|
Gain error |
≤1dB |
|
Sampling length |
4k sampling points |
|
System dynamic range |
≥66dB |
|
Reference sensitivity |
Accelerometer uncertainty (k=3) 3%; Speedometer uncertainty (k=3) 5% |
|
Power supply |
External AC220V/DC12V; Internal 12V rechargeable lithium battery (≥6h continuous operation) |
|
Temperature adaptability |
-10～+40℃ (working); -20～+65℃ (storage) |
|
Dimension |
250×200×100mm |
|
Net weight |
1.8kg |
|
Pile parameter range |
Length 0.5m~200.0m; Diameter 20mm~4000mm; Wave velocity 100m/s~10000m/s |
Features
● High-precision detection performance: Equipped with high-resolution A/D conversion and wide frequency response, ensuring accurate capture and analysis of pile reflection wave signals
● Intelligent operation system: Supports flexible parameter setting for different pile types, with real-time waveform display and multi-functional signal analysis, easy for on-site operation
● Portable compact design: Light weight and small volume, built-in rechargeable lithium battery for long continuous working time, perfect for field testing in various construction sites
● Comprehensive signal processing: With integration, filtering, amplification and spectrum analysis functions, effectively highlight useful signals and accurately locate pile defects
● Convenient data management: Realizes local data storage, U disk data transmission and waveform review, supporting post-processing analysis with professional PC software
● Humanized interface design: Configures help information area and simple key operation, with clear waveform display and intuitive parameter adjustment, reducing operation difficulty
● Strong environmental adaptability: Stable performance in a wide temperature range, dust and moisture resistant design, suitable for complex on-site construction environments
● Multi-pile type adaptation: Supports detection of precast piles, cast-in-situ piles, steel piles and other pile types, with adjustable wave velocity and pile parameters for diverse testing needs
Applications
Wireless Pile Dynamic Detector is widely used in building construction, acceptance, reinforcement, renovation and supervision.
